According to the NEC, panelboards are used in a wide range of electrical supply systems. They are used to control light, heat or power circuits, are placed in a cutout box, mounted against a wall and are accessible only from the front.
When you have a major system running through a large or complex structure, you need a good panelboard. An I-Line combo panelboard by Square D combines NQ and NF lighting sections with the I-Line power section in one enclosure. This saves time, space, and money and is ideal for many kinds of projects. Customers have asked us some questions about using LA36400 breaker in this panelboard. We have answered them below. We hope this will help you determine if this is the right product for your project.
If you have additional questions, contact your supplier or reach out to your fellow electricians online.
